Ubiquiti UniFi USW-PRO-48 Managed 48-port Gigabit Switch with SFP+

Ubiquiti UniFi USW-PRO-48 Managed 48-port Gigabit Switch with SFP+

Ubiquiti UniFi USW-PRO-48 Managed 48-port Gigabit Switch with SFP+

SKU: USW-Pro-48

Only 5 products left!

Regular price $599.00

The USW-Pro-48 is a robust and scalable Layer 3 managed switch from Ubiquiti’s UniFi Pro series. Designed for enterprise-grade networks, it offers 48× Gigabit RJ45 ports and 4× 10G SFP+ uplink ports, delivering reliable, high-capacity connectivity for core and distribution layers.

With silent cooling, a sleek rackmount design, and a front-facing 1.3" LCM touchscreen, the USW-Pro-48 allows easy monitoring and diagnostics. Managed via the UniFi Network Controller, it supports advanced features like VLANs, port profiles, static routing, and real-time traffic insights.

  • 48× Gigabit RJ45 ports
  • 4× 10G SFP+ uplink ports
  • Layer 3 capabilities with static routing
  • 1.3" touchscreen for device monitoring
  • Near-silent, fanless cooling design
  • Seamless UniFi Network Controller integration
  • Rackmount form factor for data centers or IT closets
Dispatch in: Calculating...
  • guaranteeQuality checked
  • Flat ShippingFlat on all products
  • Free return Within 30 days

Dimensions
442 x 285 x 44 mm (17.4 x 11.2 x 1.7")
Port Layout



1 GbE RJ45
48 (1G/100M/10M)


10G SFP+
4 (10G/1G)
Redundancy
DC Power Backup

Layer 3
Form Factor
Rack mount (1U)

Switching Capacity
176 Gbps
Total Non-Blocking Throughput
88 Gbps
Forwarding Rate
131 Mpps
Supported VLANs
1,000
MAC Address Table Size
16,000
L3 Table Size



ARP Entries
4,000


IPv4 Routes
1,000
Packet Buffer Size
4 MB
Access Lists



IPv4
128


MAC
128

DHCP Server (Local Networks)
DHCP Relay
Inter-VLAN Routing (Local Networks)
Static Routing (Local Networks)

LACP Port Aggregation
STP & RSTP
QoS (DSCP)
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection

Max. Power Consumption
60W
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 60W
Supported Voltage Range
100—240V AC
Management
Ethernet AR
Heat Dissipation (Excluding PoE Output)
204.72 BTU/hr
Weight
Without mounting brackets: 4 kg (8.8 lb) With mounting brackets: 4.1 kg (9 lb)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Supported Rack Depth
400~1200 mm (15.7-47.2")
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, Anatel

Application Requirements



UniFi Network
Version 5.12.11 and later

The USW-Pro-48 is a robust and scalable Layer 3 managed switch from Ubiquiti’s UniFi Pro series. Designed for enterprise-grade networks, it offers 48× Gigabit RJ45 ports and 4× 10G SFP+ uplink ports, delivering reliable, high-capacity connectivity for core and distribution layers.

With silent cooling, a sleek rackmount design, and a front-facing 1.3" LCM touchscreen, the USW-Pro-48 allows easy monitoring and diagnostics. Managed via the UniFi Network Controller, it supports advanced features like VLANs, port profiles, static routing, and real-time traffic insights.

  • 48× Gigabit RJ45 ports
  • 4× 10G SFP+ uplink ports
  • Layer 3 capabilities with static routing
  • 1.3" touchscreen for device monitoring
  • Near-silent, fanless cooling design
  • Seamless UniFi Network Controller integration
  • Rackmount form factor for data centers or IT closets
