Ubiquiti U6-Mesh-Pro UniFi Indoor/Outdoor WiFi 6 Access Point

Ubiquiti U6-Mesh-Pro UniFi Indoor/Outdoor WiFi 6 Access Point

Ubiquiti U6-Mesh-Pro UniFi Indoor/Outdoor WiFi 6 Access Point

SKU: U6-Mesh-Pro

Only 5 products left!

Regular price $199.00

Key Features

  • Tri-band Wi‑Fi 6 (2.4 GHz, 5 GHz Low, 5 GHz High)
  • 4x4 MU-MIMO and OFDMA support
  • Up to 5.3 Gbps aggregate wireless throughput
  • 1× 2.5 GbE Ethernet port with PoE+
  • Weather-resistant (outdoor-rated housing)
  • Flexible pole or wall mounting options
  • Seamless integration with UniFi Network Controller
Dispatch in: Calculating...
  • guaranteeQuality checked
  • Flat ShippingFlat on all products
  • Free return Within 30 days

Brand Ubiquiti Networks
Model Name U6-Mesh-Pro
Special Feature Access Point Mode
Frequency Band Class Dual-Band
Communication Standard 802.11n,Wireless
Compatible Devices Personal Computer
Frequency 5 GHz
Uses For Product Home, Business
Included Components Power supply, hardware kit
Connectivity Technology Ethernet
WiFi Standard WiFi 6
Spatial Streams 4
Coverage Area 185 m² (2,000 ft²)
Max. Client Count 250+
Uplink GbE
Mounting Wall, Pole (Mounts Included)
Weatherproofing IPX6
Power Method PoE
MIMO
5 GHz 2 x 2 (DL/UL MU MIMO)
2.4 GHz 2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz 2.4 Gbps (BW160)
2.4 GHz 573.5 Mbps (BW40)
Antenna Gain
5 GHz 8 dBi
2.4 GHz 8 dBi
Max. TX Power
5 GHz 27 dBm
2.4 GHz 22 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15 , HT 20/40)
Features
Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN
Hardware
Max. Power Consumption 9W
Includes PoE Adapter
Supported Voltage Range 42.5—57V DC
Networking Interface (2) GbE RJ45 ports
Weight 819 g (1.8 lb)
Pole Mount Diameter 1–2.5″ (25–63.5 mm)
Management Ethernet WiFi
Enclosure Material UV-stabilized polycarbonate
Mount Material Aluminum alloy, steel
LEDs
System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
NDAA Compliant
Certifications CE, FCC, IC, Anatel
Operating Frequency US/CA: 2400 – 2472 MHz U-NII-1: 5150 – 5250 MHz U-NII-2A: 5250 – 5350 MHz U-NII-2C: 5470 – 5725 MHz U-NII-3: 5725 – 5850 MHz Worldwide: 2400 – 2483.5 MHz 5150 – 5725 MHz
Ambient Operating Temperature -30 to 60° C (-22 to 140° F)
Ambient Operating Humidity 5 to 95% noncondensing
Software
UniFi Network Version 8.1.127 and later
Dimensions 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4″)


Key Features

  • Tri-band Wi‑Fi 6 (2.4 GHz, 5 GHz Low, 5 GHz High)
  • 4x4 MU-MIMO and OFDMA support
  • Up to 5.3 Gbps aggregate wireless throughput
  • 1× 2.5 GbE Ethernet port with PoE+
  • Weather-resistant (outdoor-rated housing)
  • Flexible pole or wall mounting options
  • Seamless integration with UniFi Network Controller
