Ubiquiti UniFi Protect Network Video Recorder (UNVR)

Ubiquiti UniFi Protect Network Video Recorder (UNVR)

Ubiquiti UniFi Protect Network Video Recorder (UNVR)

SKU: UNVR

Only 5 products left!

Regular price $299.00

The UniFi UNVR is a scalable, rack-mountable 4-bay network video recorder built for seamless integration with the UniFi Protect platform. Designed for business and enterprise surveillance deployments, it combines powerful storage capabilities with centralized video management.

Equipped with four 3.5" HDD bays, it supports up to 30 days of 4K video storage (depending on camera count and drive size) and offers RAID 1 configuration for data redundancy and protection.

  • Supports up to 50 UniFi Protect cameras
  • Four 3.5" HDD bays, each supporting up to 8TB drives
  • RAID 1 configuration for improved data reliability
  • Integrated with UniFi Protect for easy camera management and playback
  • 1U rack-mount design for space-efficient deployment
  • Powered by Gigabit Ethernet (RJ45) and internal power supply
  • Compact, silent, and efficient operation for 24/7 surveillance
Dispatch in: Calculating...
  • guaranteeQuality checked
  • Flat ShippingFlat on all products
  • Free return Within 30 days

Dimensions
442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
UniFi Application Suite

Protect
Access
Managed Cameras
(60) HD (30) 2K (18) 4K
Managed Access Hubs
150
Storage Capacity
(4) 3.5" drive bays
Data Protection
Vantage Point
Networking Interface
(1) 10G SFP+ port (1) GbE RJ45 port
Power Redundancy

Form Factor
Rack mount (1U)
Door Access Support

Hard Drive Capacity
(4) 2.5/3.5” HDD / SSD support
Max. Power Budget for Drives
75W
Max. Power Consumption
100W
Power Method
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 10.43A
Power Supply
AC/DC, internal, 120W
Processor
Quad ARM® Cortex®-A57 cores at 1.7GHz
Memory
4GB
Management
Ethernet
Weight
Without mounting brackets: 5.1 kg (11.3 lb) With mounting brackets: 5.2 kg (11.5 lb)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, SRRC

The UniFi UNVR is a scalable, rack-mountable 4-bay network video recorder built for seamless integration with the UniFi Protect platform. Designed for business and enterprise surveillance deployments, it combines powerful storage capabilities with centralized video management.

Equipped with four 3.5" HDD bays, it supports up to 30 days of 4K video storage (depending on camera count and drive size) and offers RAID 1 configuration for data redundancy and protection.

  • Supports up to 50 UniFi Protect cameras
  • Four 3.5" HDD bays, each supporting up to 8TB drives
  • RAID 1 configuration for improved data reliability
  • Integrated with UniFi Protect for easy camera management and playback
  • 1U rack-mount design for space-efficient deployment
  • Powered by Gigabit Ethernet (RJ45) and internal power supply
  • Compact, silent, and efficient operation for 24/7 surveillance
