Ubiquiti UDM-PRO UniFi Dream Machine Pro Gateway & 8-Port Switch

Ubiquiti UDM-PRO UniFi Dream Machine Pro Gateway & 8-Port Switch

Ubiquiti UDM-PRO UniFi Dream Machine Pro Gateway & 8-Port Switch

SKU: UDM-Pro

Only 5 products left!

Regular price $379.00

All-in-one enterprise security gateway & network appliance for small to medium-sized businesses. The optimal experience for larger networks. UniFi Dream Machine Pro (UDM-Pro) is an all-in-one enterprise network appliance.

UDM-Pro integrates all current and upcoming UniFi controllers with a security gateway, 10G SFP+ WAN, 8-port Gbps switch and off-the-shelf 3.5" HDD support.

All-in-one 1U rack appliance for small to medium sized businesses Combines new UniFi OS with 8-port switch and security gateway UniFi Protect video surveillance NVR with off-the-shelf 3.5" HDD support 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities Powered by fast 1.7 GHz quad-core processor.

Key Features

  • Advanced UniFi Security Gateway with built-in switch.
  • Eight (8) port Gigabit switch with 10GbE SFP+ port.
  • One (1) unpopulated NVR hard drive bay.
  • Dual WAN ports for redundancy: 10GbE SFP+ and 1GbE RJ45.
  • Bluetooth connectivity for easy setup via UniFi app.
  • Embedded Enterprise Software: UniFi Network.
  • Scalable UniFi Network Controller with advanced management capabilities.
  • UniFi Protect video surveillance NVR with 3.5" (or 2.5") HDD support (see accessories tab).
  • Enterprise-class IPS/IDS and DPI capabilities.
  • 1.3" Touchscreen display for quick status information.
  • Powered by fast 1.7 GHz quad-core processor.
  • Significantly greater performance over the previous generation of UniFi Security Gateways.
Dispatch in: Calculating...
  • guaranteeQuality checked
  • Flat ShippingFlat on all products
  • Free return Within 30 days

Dimensions
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
UniFi Application Suite

Network
Protect
Access
Talk
Connect
Managed UniFi Devices
100+
Managed Cameras
(24) HD (14) 2K (8) 4K
Managed Access Hubs
150
Simultaneous Users Connected
1,000+
Max. WAN Port Count
8
Default WAN Ports
(1) 10G SFP+ (1) GbE RJ45
Port Layout

1 GbE RJ45
9 (1G/100M/10M)
10G SFP+
2 (10G/1G)
IDS/IPS Throughput
3.5 Gbps
Form Factor
Rack mount (1U)
Redundancy
Shadow Mode (VRRP) Gateway Failover DC Power Backup


Stateful Firewall
Application-Aware Layer 7 Firewall
DPI & Traffic Identification
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
Content Filtering
Intrusion Prevention (IPS/IDS)
Ad Blocking
IDS/IPS Signatures
55,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation

License-Free SD-WAN
Site-to-Site VPN

Site Magic
IPsec
OpenVPN
VPN Server

Identity Endpoint One-Click VPN
Teleport Zero-Configuration VPN
WireGuard
OpenVPN
L2TP
VPN Client

OpenVPN
WireGuard

Multi-WAN Load Balancing
Shadow Mode (VRRP) High Availability
Dynamic Routing

OSPF
BGP
Advanced QoS
Multicast DNS (mDNS)
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
Integrated RADIUS Server
RADIUS over TLS (RadSec)
Additional Internet Failover with UniFi LTE Backup
Internet Quality and Outage Reporting
MAC Address Table Size
4,000
Policy-based WAN and VPN Routing
Customizable DHCP Server
IPv6 ISP Support
IGMP Proxy

NVR Storage
(1) 3.5" NVR HDD bay
Max. Power Consumption
33W
Power Method
(1) Universal AC input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input
Power Supply
AC/DC, internal, 50W
Supported Voltage Range
100—240V AC
Processor
Quad-core ARM® Cortex®-A57 at 1.7 GHz
System Memory
4 GB
On-board Storage
16 GB
Weight
3.9 kg (8.6 lb)
Enclosure Material
Aluminium CNC, SGCC steel
Mount Material
SGCC steel
LCM Display
1.3" touchscreen
Management
Ethernet Bluetooth
LEDs

Ethernet
SFP+
RPS
PSU
HDD
Button
(1) Factory-reset
ESD/EMP Protection
Air: ± 15kV, contact: ± 8kV
Ambient Operating Temperature
-10 to 40° C (14 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, Anatel, SRRC

All-in-one enterprise security gateway & network appliance for small to medium-sized businesses. The optimal experience for larger networks. UniFi Dream Machine Pro (UDM-Pro) is an all-in-one enterprise network appliance.

UDM-Pro integrates all current and upcoming UniFi controllers with a security gateway, 10G SFP+ WAN, 8-port Gbps switch and off-the-shelf 3.5" HDD support.

All-in-one 1U rack appliance for small to medium sized businesses Combines new UniFi OS with 8-port switch and security gateway UniFi Protect video surveillance NVR with off-the-shelf 3.5" HDD support 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities Powered by fast 1.7 GHz quad-core processor.

Key Features

  • Advanced UniFi Security Gateway with built-in switch.
  • Eight (8) port Gigabit switch with 10GbE SFP+ port.
  • One (1) unpopulated NVR hard drive bay.
  • Dual WAN ports for redundancy: 10GbE SFP+ and 1GbE RJ45.
  • Bluetooth connectivity for easy setup via UniFi app.
  • Embedded Enterprise Software: UniFi Network.
  • Scalable UniFi Network Controller with advanced management capabilities.
  • UniFi Protect video surveillance NVR with 3.5" (or 2.5") HDD support (see accessories tab).
  • Enterprise-class IPS/IDS and DPI capabilities.
  • 1.3" Touchscreen display for quick status information.
  • Powered by fast 1.7 GHz quad-core processor.
  • Significantly greater performance over the previous generation of UniFi Security Gateways.
