Ubiquiti U7-Lite Unifi WiFi 7 Access Point

Ubiquiti U7-Lite Unifi WiFi 7 Access Point

Ubiquiti U7-Lite Unifi WiFi 7 Access Point

SKU: U7-Lite

In Stock — 10 available

Regular price $94.00
  • Tri-band Wi‑Fi 7 (6 GHz, 5 GHz, 2.4 GHz)
  • 2x2 MU-MIMO on each band
  • Up to 3.5 Gbps combined wireless throughput
  • 1 GbE PoE+ uplink port
  • Supports 150+ simultaneous client devices
  • Coverage up to 140 m² (1,500 ft²)
  • Compact, fanless design for silent operation
  • Wall or ceiling mountable
  • Managed via UniFi Network Controller
Dispatch in: Calculating...
  • guaranteeQuality checked
  • Flat ShippingFlat on all products
  • Free return Within 30 days

Brand Ubiquiti
Model Name Ubiquiti UniFi U7 Lite
Frequency Band Class Dual-Band
Communication Standard 802.11.be Wireless
Included Components Plate
Connectivity Technology Wi-Fi, Ethernet
LAN Port Bandwidth 2500000000 bps
WiFi Standard WIFi 7
Spatial Streams 4
Coverage Area 115 m² (1,250 ft²)
Max. Client Count 200+
Uplink 2.5 GbE
Mounting Ceiling, Wall (Lite Mount Included)
Power Method PoE
MIMO
5 GHz 2 x 2 (DL/UL MU-MIMO)
2.4 GHz 2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz 4.3 Gbps (BW240)
2.4 GHz 688 Mbps (BW40)
Antenna Gain
5 GHz 5 dBi
2.4 GHz 4 dBi
Max. TX Power
5 GHz 24 dBm
2.4 GHz 23 dBm
Max. BSSIDs 8 per Radio
Supported Data Rates
802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11n 6.5 Mbps to 300 Mbps (MCS
Features
Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN
Hardware
Max. Power Consumption 13W
Supported Voltage Range 42.5—57V DC
Networking Interface (1) 2.5 GbE RJ45 port
Weight 313 g (11 oz)
Management Ethernet
Enclosure Material UV-stabilized polycarbonate
Mount Material UV-stabilized polycarbonate, galvanized steel (SGCC)
LEDs
System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
NDAA Compliant
Certifications CE, FCC, IC, Anatel
Ambient Operating Temperature -30 to 40° C (-22 to 104° F)
Ambient Operating Humidity 5 to 95% noncondensing
Software
UniFi Network Version 9.0.114 and later
Mobile App iOS™ version 10.20.2 and later Android™ version 10.21.7 and later
Dimensions Ø171.5 x 33 mm (Ø6.8 x 1.3″)


  • Tri-band Wi‑Fi 7 (6 GHz, 5 GHz, 2.4 GHz)
  • 2x2 MU-MIMO on each band
  • Up to 3.5 Gbps combined wireless throughput
  • 1 GbE PoE+ uplink port
  • Supports 150+ simultaneous client devices
  • Coverage up to 140 m² (1,500 ft²)
  • Compact, fanless design for silent operation
  • Wall or ceiling mountable
  • Managed via UniFi Network Controller
